| Operational mode: | NMRA/DCC with 14, 28, 128 speed steps |
| DCC 2-digit and 4-digit addresses | |
| Digital Motorola® (old and new), up to 28 speed steps and 127 addresses in Motorola® operation | |
| Analog DC (de-selectable). Analog AC (de-selectable) | |
| Automatic recognition of operational mode and DCC step speed selection | |
| Supports Lenz® LG100, Märklin®, Roco® braking sections | |
| Wrong-direction bit / Stores operational status (Memory) | |
| Intelligent programming mode with Märklin® 6021® | |
| Throttle: | 3.0 A continuous load |
| Runs DC-, coreless and AC motors (AC motors can only be used when changed into DC via a permanent magnet) | |
| Silent, safe 16 / 32 kHz pulse width frequency motor regulation | |
| Motor output overload protection. Load control of fourth generation (back EMF and de-selectable) | |
| Function outputs: | 8 outputs |
| 600mA load per output | |
| Approx. 2000mA total load of all function outputs. Outputs short circuit protected. | |
| Free funtion allocation (function mapping) F0 - 20 | |
| Sound features: | 4 (!) independent sound channels |
| High performance bridge-tied load amplifier, ca. 1.5 Watt | |
| Sound data in memory unit changeable | |
| Modes for steam engines, diesel hydraulic locos, diesel electrical locos, Electro locos | |
| 16 MBit storage capacity (up to 130 seconds) | |
| Loud speaker: | NOT INCLUDED. Adequate loud speakers between 8 and 32 ohm, at least 2 Watt |
| Dimensions: | 51.0mm x 40.0mm x 14.0mm (2.04 x 1.6 x 0.56 inch) |
Please note:
Decoder can be used on Selectrix® layouts. Programming in DCC mode only. Programming with exclusive Selectrix® devices not possible.
